FPJSON (Functional Programmable JSON)

FPJSON is a dmain specific language (DSL) for WeaveDB, and what makes a fully decentralized DB possible.

Apart from performance and scalability, you cannot just bring in an existing web2 database and decentralize it. A web3 database requires highly advanced logic around data ownerships, programmable data manipurations, and access control rules due to the permissionless nature.

Unlike web2 databases with only a few access gateways for admin users, anyone can write anything to a web3 DB from anywhere. We need precise controls over everything but in a decentralized fashion.

WeaveDB has decentralized features such as

  • Crypto Account Authentication to manage data access and ownerships
  • Data Schemas to constrain stored data format
  • Access Control Rules to manage write permissions and manipulate data
  • Crons to periodically execute queries
  • Triggers to chain queries with pre-defined logic
  • Verifiable Relayers to bring in data from outside data sources

Without these features, a web3 database would either be out of control or have only limited use cases. And all these are enabled by FPJSON as the simplest JSON style settings. FPJSON enables highly advanced, and composable functional programming in a simple JSON format, which makes WeaveDB itself the most powerful smart contract sandbox as well.

Basic FPJSON Blocks

FPJSON is based upon Ramda.js which comes from the functional programming ecosystem (I believe it's heavily inspired by Haskell). You can use most of the 250+ pre-defined Ramda functions, and compose them in any depth of complexity, but in a simple JSON array format. The biggest advantage of JSON style programming is we can store any logic as a JSON data object as a smart contract state and reuse them to compose with other logic. This is the only viable (yet super powerful) way to dynamically construct, compose and extend logic after smart contract is immutably deployed without deploying a new contract.

Basic FPJSON blocks look something like these.


["add", 1, 2] // = 3

["difference", [1, 2, 3], [3, 4, 5]] // = [1, 2]

[["map", ["inc"]], [1, 2, 3]] // = [4, 5, 6]

[["compose", ["map", ["inc"]], ["difference"]], [1, 2, 3], [2]] // = [2, 4]

Learn the 250+ powerful functions here.

Access Control Rules with FPJSON

One big constraint of FPJSON is we can only do pure functional programming with point-free style, which means functions cannot have arguments. Functional programming is extremely powerful, but pure FP sometimes makes it overly complicated and impractical to build a simple logic.

WeaveDB elegantly extends the base FPJSON to makes it easier and more practical by injecting side-effect variables and imperative programming features such as if-else conditional statement.

allow() / deny()

The simplest form of access control rules is just allow everything.

["set", ["allow()"]]

or deny everything.

["set", ["deny()"]]

Pattern Matching

The first element is an accepted operation and the condition will be evaluated only if the query matches the operation.

  • add | set | update | upsert | del : these matche query types

You can always use the basic operation types, but a better solution is define custom operations such as add:post and del:post.

["add:post", ["allow()"]]

The first part of a custome tag matches query types, and the second part is an arbitrary operation name.

  • custome tag: type:name
  • types: add | set | update | upsert | del

In this way, users will only be able to execute the preset custom queries, so you will be in better control.

await db.set("add:post", {title: "Test", body: "hello"}, "posts")

Preset Variables

You can access preset variables in access rule evaluations as explained here.

let vars = {
  op, // set:post
  opcode, // set
  operand, // post
  id, // database ID
  owner // database owner
  signer, // message signer
  ts, // timestamp
  dir, // directory
  doc, // document ID
  query, // query
  before, // data before updating
  after, // data after updating
  allow: false, // auth passes if allow is eventually true
}

For instance, if { title: "Title", body: "hellow" } is already stored, and the query is updating { body: "bye" }, the following is what will be assigned.

  • $before : { title: "Title", body: "hellow" }
  • $after : { title: "Title", body: "bye" }

mod()

mod() will manipulate the uploading data before commiting permanently.

[ "add:post", [ [ "mod()", { id: "$id", owner: "$signer", date: "$ts" } ], ["allow()"] ] ]

This will set id to the auto-generated docID, owner to the transaction signer, and date to the transaction timestamp.

const tx = await db.set("add:post", {title: "Test", body: "hello"}, "posts")

const post = await db.get("posts", tx.docID)
// the post has the extra fields auto-assigned : { title, body, id, owner, date }

This is how you can control the values of updated fields and minimize the fields users will upload.

fields()

You can also constrain the user updated fields with fields(), and it works great with mods().
In the previous example, you only want users to update title and body, not anything else.
Use ["fields()", ["title", "body"]] for such an restriction.

[
  "add:post",
  [
    ["fields()", ["title", "body"]],
    ["mod()", { id: "$id", owner: "$signer", date: "$ts" }],
    ["allow()"],
  ],
]

* will make the field mandatory. e.g. ["fields()", ["*title", "*body"]]

// these will be rejected
await db.set("add:post", {title: "Test", body: "hello", id: "abc"}, "posts")
await db.set("add:post", {title: "Test"}, "posts") // missing mandatory body

You can also individually whitelist and blacklist fields with requested_fields() and disallowed_fields() respectively.

=$

=$ will assign the result of the following block to a variable. You can use FPJSON logic in the second block.

// this will check if the signer is the post owner
["=$isOwner", ["equals", "$signer", "$before.owner"]]

allowif() / allowifall()

Assigned variables can be used in any later blocks. It's especially useful when combined with allowif().

[
  "delete:post",
  [
    ["=$isOwner", ["equals", "$signer", "$before.owner"]], // the second block is FPJSON
    ["allowif()", "$isOwner"], // allow if the second element is true
  ],
]

You can use multiple conditions with allowifall(). The following also checks if the signer is the database owner.

[
  "delete:post",
  [
    ["=$isDataOwner", ["equals", "$signer", "$before.owner"]],
    ["=$isDBOwner", ["equals", "$signer", "$owner"]],
    ["allowifall()", ["$isOwner", "$isDBOwner"],
  ],
]

You can use allowifany(), denyif(), denyifall(), denyifany(), breakif() in the same principle.

get()

get() allows you to query other data during access evaluations.
The following checks if the signer exists in users collection. It's equivalent to await data.get("users", "$signer").

[
  "add:post",
  [
    ["=$user", ["get()", ["users", "$signer"]]],
    ["=$existsUser", [["complement",["isNil"]], "$user"]],
    ["allowif()", "$existsUser"],
  ],
]

Shortcut Symbols

As you can see, functional programming can get a bit too verbose for simple logic like $existsUser. So we have a bunch of shortcut symbols to make it more pleasant.

  • o$ : ["complement",["isNil"]] : true if data exists
  • x$ : ["isNil"] : true if data is null or undefined
  • !$ : ["not"] : flip boolean
  • l$ : ["toLower"] : lowercase
  • u$ : ["toUpper"] : uppercase
  • $ : ["tail"] : remove the first element, useful for escaping in FPJSON

For instance, you can simplify the previous example as follows.

[
  "add:post",
  [
    ["=$user", ["get()", ["users", "$signer"]]],
    ["allowif()", "o$user"], // true if $user exists
  ],
]

if-else conditions

Sometimes you want to execute some blocks only if a certain condition is met.
if executes the third block only if the second block evaluates true.

["if", "o$user", ["=$existsUser", true]]

You can combine if with elif and else.

["=$existsUser", ["if", "o$user", true, "else", false]]

User break to exit the whole evaluation without allow() and deny().

["if", "x$user", ["break"]]

In this case, the query validity depends on other matched conditions. For example, you could define conditions for add:post, but also another condition for add and the query matches both patterns.

Helper Functions

split()

It's often useful to make the docID deterministic with some document fields. For example, express follow relationships, you would set the docID fromUserID:toUserID, in this case, split() comes in handy.

[
  "set:follow",
  [
    // split docID with ":" and assign to $from_id and $to_id
    ["split()", [":", "$id", ["=$from_id", "=$to_id"]]],
	["=$isFromSigner", ["equals", "$from_id", "$signer"]],
	["mod()", { from: "$from_id", to: "$to_id", date: "$ms" }],
    ["allowif()", "$isFromSigner"]
  ],
]

Now users can send an empty query as long as the docID checks out.

await db.set("set:follow", {}, "follows", "fromUserID:toUserID")

parse()

equivalent to JSON.parse().

stringify()

equivalent to JSON.stringify().
